A-10A s/n AF 78-0583
USAF 104 FW, NAS Norfolk,
Oct 1999
Starboard outer wing section with aileron.
Inboard tab moves inversely proportional to aileron.
Tab pitch with aileron in neutral position is slightly larger than that
of the outboard fixed tab.
Photo by Gunnar von
Schaewen
|
